Concreto 24V

The Concreto is a surface mounted can light, suitable for general lighting in interior and exterior areas, such as above a BBQ, outdoor dining, kitchen islands and dining tables. There are four finishes for the fitting and for the insert/reflector available, which can be mixed and matched.

SPECIFICATIONS

Power: 8W

Lumen Output: 700lm

Colour Temperature: 3000K

Cut Out: Surface Mounted

Depth: 140mm

Adjustability: Fixed

CRI: 80-90

IP Rated: 20, 44 on request.

Wiring Info: 240V to driver remote. If more than one light, must be wired in parallel.

Input: 24V

Beam Angle: 60°

Dimming: DALI, Phase, CCT Tunable White

CCT Tunable White: 2700K-6500K

CCT Wiring: Requires 3-core cables: warm white, cool white and a positive cable.

Warranty: 3 years.

FINISH OPTIONS

All fitting finishes and insert/reflector finishes can be mixed and matched depending on desired look.

Fitting Finish: Pure White

Insert/Reflector Finish: Glossy White

Fitting Finish: Black Sandstone

Insert/Reflector Finish: Glossy Black

Fitting Finish: Grey Concrete

Insert/Reflector Finish: Copper

Fitting Finish: White Sandstone

Insert/Reflector Finish: Glossy Metallic Silver

CONTROL GEAR OPTIONS

• 4W 3000k GU10 Globe - No Driver Needed (Non-Dimmable)
• 4W 3000k MR16 Globe - Remote Driver Required (Dimmable)
• 4W 3000k GU10 Globe - No Driver Needed (Non-Dimmable)
• 4W 3000k MR16 Globe - Remote Driver Required (Dimmable)

DRIVER OPTIONS

• 36W/12V Driver (Dimmable) - Remote Driver
• 75W/12V Driver (Dimmable) - Remote Driver
• 36W/12V Driver (Dimmable) - Remote Driver
• 75W/12V Driver (Dimmable) - Remote Driver
