10W IP20 Continuous LED Strip
The 10W IP20 Continuous LED Strip is a dot free LED strip which is available in 5m/roll packets. This LED strip provides seamless and sophisticated LED lighting and is ideal for a range of LED profiles, including shallow LED profiles.
SPECIFICATIONS
Power: 10W LED
Lumen Output: 900lm per metre
Colour Temperature: 3000K, 2700K on request.
Width: 8mm
Length: 5m roll per packet.
Adjustability: Fixed CRI: 90-95
IP Rated: 20
Wiring Info: 240V or DALI to driver remote, low voltage to strip.
Input: 24V
Beam Angle: 120°
Dimming: DALI, Phase.
Warranty: 3 years.
CONTROL GEAR OPTIONS
-
• 36W/24V Driver (Dimmable) - Remote Driver
• 75W/24V Driver (Dimmable) - Remote Driver
• 150W/24V Driver (Dimmable) - Remote Driver
• 240W/24V Driver (Dimmable) - Remote Driver
-
• 36W/24V Driver (Dimmable) - Remote Driver
• 75W/24V Driver (Dimmable) - Remote Driver
• 150W/24V Driver (Dimmable) - Remote Driver
• 240W/24V Driver (Dimmable) - Remote Driver
WIRING INFORMATION
Constant Voltage 24V Drivers MUST be wired in parallel. See the below diagram on how to wire in parallel.
Constant Voltage 24V Drivers MUST be wired in parallel. See the below diagram on how to wire in parallel.
DOWNLOADS
Photometric IES Files
